Performance | |
Drawbar Pull | 23000 lb / 10432.62 kg |
Frame Leveling | 8 Degrees |
Lift Capacity at Full Height | 9900 lb / 4490.56 kg |
Lift Capacity at Max Reach | 5500 lb / 2494.76 kg |
Load Center | 2 ft / 0.61 m |
Maximum Lift Capacity | 16755 lb / 7599.94 kg |
Maximum Lift Height | 31 ft 8 in. / 9.65 m |
Maximum Reach | 18 ft 7 in. / 5.66 m |
Outriggers or Stabilizers | No |
Outside Turning Radius | 13 ft 2 in. / 4.01 m |
Speed - Maximum Lift | 14.1 sec. |
Speed - Maximum Lower | 10.9 sec. |
Speed - Maximum Telescope In | 10.9 sec. |
Speed - Maximum Telescope Out | 13.2 sec. |
Speed - Maximum Travel | 20 mph / 32.19 km/h |
